I. Introduction
At present, the most dream-like and top-tier configuration for gamers is undoubtedly the Ryzen 7 9800X3D + GeForce RTX 5090. However, this setup is quite expensive and is only suitable for a small number of high-end gamers.
On the other hand, the Ryzen 7 7800X3D + GeForce RTX 5070 Ti offers a more cost-effective and practical choice. So, how does this configuration perform in real-world use? This article will reveal the answer through testing, for the reference of interested readers.
II. Specifications Review
The GeForce RTX 5070 Ti was released on January 6, 2025. It uses the GB203 GPU chip built on TSMC’s 5nm process, featuring 8960 CUDA cores, 280 texture units, 70 multi-process units, 280 tensor cores, and 70 ray tracing units.
It has a 64MB L2 cache, with a base clock of 2295MHz and a boost clock of up to 2452MHz. It comes with 16GB of GDDR7 VRAM, a 256-bit memory interface, a memory speed of 28Gbps, and a memory bandwidth of 896GB/s. The FP32 floating point performance is 43.94 TFLOPS, with a power consumption of 300W, and a reference price of $749.
The Ryzen 7 7800X3D was released on January 4, 2023. It is built on TSMC’s 5nm process, with 8 cores and 16 threads. It has a 512KB L1 cache, 8MB L2 cache, and 96MB L3 cache.
The base clock is 4.2 GHz, with a maximum clock of 5.0 GHz. The power consumption is 105W, and it integrates two display cores running at 2200MHz. The suggested retail price is $449.
III. Test Platform Configuration (Ryzen 7 7800X3D with RTX 5070 Ti)
The main configuration is as follows:
- Processor: Ryzen 7 7800X3D
- Motherboard: MSI MPG X670E CARBON
- Memory: 32GB DDR5 6000 MHz
- Graphics Card: GeForce RTX 5070 Ti
- Storage: Two Samsung 970 EVO 1TB SSDs
- Operating System: Windows 11
IV. Game Tests (Ryzen 7 7800X3D with RTX 5070 Ti)
The following tests were conducted on seven games, all using the highest 4K graphics settings.
The first game is Ghostwire: Tokyo.
- Average frame rate: 51 FPS
- Minimum instantaneous frame rate: 45 FPS
- Frame time: 18.9 ms
- CPU usage: 11%
- Power consumption: 43W
- Temperature: 51°C
- Memory usage: 11.9GB
- GPU usage: 99%
- VRAM usage: 9.9GB
- Power consumption: 278W
- Temperature: 56°C
In this game, CPU usage is around 10%, memory usage is around 12GB, the GPU is fully utilized, and VRAM usage is around 10GB.
The average frame rate is around 50 FPS, with a minimum instantaneous frame rate above 40 FPS and frame time around 19 ms, providing smooth performance without significant issues.
The second game is God of War.
- Average frame rate: 99 FPS
- Minimum instantaneous frame rate: 80 FPS
- Frame time: 9.9 ms
- CPU usage: 27%
- Power consumption: 58W
- Temperature: 63°C
- Memory usage: 12.1GB
- GPU usage: 99%
- VRAM usage: 8.3GB
- Power consumption: 293W
- Temperature: 57°C
In this game, CPU usage is about 27%, almost one-third of the total capacity. Memory usage is around 12GB, and the GPU is fully utilized with VRAM usage slightly above 8GB.
The average frame rate reaches around 99 FPS, with a minimum instantaneous frame rate above 80 FPS and frame time around 10 ms, showing better overall performance than the previous game.
The third game is Red Dead Redemption 2.
- Average frame rate: 89 FPS
- Minimum instantaneous frame rate: 76 FPS
- Frame time: 9.6 ms
- CPU usage: 23%
- Power consumption: 51W
- Temperature: 56°C
- Memory usage: 12.2GB
- GPU usage: 94%
- VRAM usage: 6.6GB
- Power consumption: 255W
- Temperature: 53°C
In this game, CPU usage is around 23%, close to one-quarter of the total, and memory usage is just above 12GB. The GPU is not fully utilized, and VRAM usage is between 6GB and 7GB.
The average frame rate is around 90 FPS, with a minimum instantaneous frame rate above 70 FPS and frame time around 9 ms, delivering excellent performance without any noticeable weaknesses.
The fourth game is Alan Wake 2.
- Average frame rate: 29 FPS
- Minimum instantaneous frame rate: 25 FPS
- Frame time: 31.5 ms
- CPU usage: 12%
- Power consumption: 44W
- Temperature: 51°C
- Memory usage: 12.9GB
- GPU usage: 99%
- VRAM usage: 12.2GB
- Power consumption: 281W
- Temperature: 51°C
In this game, CPU usage is about 12%, memory usage is just above 13GB, and the GPU is fully utilized with VRAM usage just over 12GB.
The average frame rate barely reaches 30 FPS, with the minimum instantaneous frame rate around 25 FPS and frame time exceeding 30 ms, making the game not run smoothly.
The fifth game is Cyberpunk 2077.
- Average frame rate: 28 FPS
- Minimum instantaneous frame rate: 24 FPS
- Frame time: 35.2 ms
- CPU usage: 32%
- Power consumption: 58W
- Temperature: 63°C
- Memory usage: 13.9GB
- GPU usage: 98%
- VRAM usage: 12.9GB
- Power consumption: 278W
- Temperature: 56°C
In this game, CPU usage is about 32%, close to one-third of the total, memory usage is around 14GB, and the GPU is nearly fully utilized with VRAM usage at around 13GB.
The average frame rate is around 28 FPS, with the minimum instantaneous frame rate around 24 FPS and frame time around 35 ms, failing to run smoothly.
The sixth game is Horizon Forbidden West.
- Average frame rate: 71 FPS
- Minimum instantaneous frame rate: 61 FPS
- Frame time: 13.6 ms
- CPU usage: 55%
- Power consumption: 73W
- Temperature: 71°C
- Memory usage: 11.3GB
- GPU usage: 99%
- VRAM usage: 10.9GB
- Power consumption: 257W
- Temperature: 52°C
In this game, CPU usage is around 55%, memory usage is just above 11GB, and the GPU is nearly fully utilized with VRAM usage around 11GB.
The average frame rate is around 70 FPS, with a minimum instantaneous frame rate around 60 FPS and frame time around 13 ms, providing smooth performance without any issues.
The seventh game is Silent Hill 2.
- Average frame rate: 61 FPS
- Minimum instantaneous frame rate: 53 FPS
- Frame time: 16.4 ms
- CPU usage: 17%
- Power consumption: 41W
- Temperature: 56°C
- Memory usage: 14.4GB
- GPU usage: 97%
- VRAM usage: 10.3GB
- Power consumption: 242W
- Temperature: 53°C
In this game, CPU usage is around 17%, memory usage is just above 14GB, and the GPU is almost fully utilized with VRAM usage around 10GB.
The average frame rate is around 60 FPS, with a minimum instantaneous frame rate above 50 FPS and frame time around 16 ms, running smoothly without any significant problems.
V. Conclusion
The test results are quite clear: the GeForce RTX 5070 Ti struggles a bit with 4K gaming, as some demanding games cannot run smoothly. However, if the graphics settings are lowered to 2K, 1440P, or 1080P, it performs without any issues.
In conclusion, for most gamers, the Ryzen 7 7800X3D + GeForce RTX 5070 Ti configuration is a viable and worthwhile option to consider.
