I. Core Definition and Unit System of Solder Paste Viscosity
Solder paste viscosity is a key indicator of internal friction, directly impacting printing performance and soldering quality. Common units include:
- Pa·s (Pascal-second): SI unit, 1 Pa·s = 1000 mPa·s.
- kcp (kilo-centipoise): Common industry unit, 1 kcp = 1000 mPa·s = 1 Pa·s. According to IPC standards, 60–140 kcp equals 60–140 Pa·s.
- cp (centipoise): 1 cp = 10 mPa·s, suitable for low-viscosity scenarios.
Standard Range Differences:
- General standard: 150–250 mPa·s (suitable for general printing).
- IPC standard: IPC-TM-650 specifies 200–300 Pa·s at 25°C.
- Broad range: 20–300 Pa·s (to cover different process requirements).
II. Test Methods and Equipment Selection
Test methods depend on precision needs and application scenarios:
Rotational Viscometer Method (Mainstream)
- Principle: Measures viscosity via rotational resistance, simulating printing shear rate.
- Equipment: Malcom PCU, Brookfield type.
- Steps:
- Let sample stand at 25°C for 30 minutes to remove bubbles.
- Set rotation speed (e.g., 10 rpm), measure for 30 seconds.
- High accuracy (±1%), but time-consuming (~15 min per test), suitable for labs.
- New detail: When using a T-type spindle, ensure immersion depth of 0.3–2.8 cm, temperature fluctuation within ±0.25°C.
Flow Cup Method (Quick Screening)
- Principle: Converts outflow time into viscosity, used for low-viscosity scenarios.
- Equipment: Tu-4 cup (5 mm orifice).
- Steps:
- Fill with solder paste, level surface, record outflow time.
- Formula: η = K × t (K = instrument constant).
- Advantages: Low cost (500–1000 RMB), simple operation (<5 min).
- Disadvantages: Low accuracy (±5%), cannot simulate shear rate.
Rheometer Testing (Thixotropy Analysis)
- Principle: Uses plate/cone shearing to measure thixotropic behavior (Ti, R values).
- Key Parameters:
- Ti (Thixotropic Index): 0.4–0.6 indicates moderate flow, quick shape change under force.
- R (Viscosity Recovery Rate): Close to 0 = good recovery, prevents post-print collapse.
Vibrational Viscometer Method (Online Monitoring)
- Principle: Real-time viscosity calculation via vibration frequency changes.
- Application: Continuous-feed printers, rapid response (<1 sec).
- Disadvantage: Moderate accuracy (±3%), requires thermostatic control.
III. Industry Standards and Key Parameter Analysis
IPC J-STD-005A Standard
- Physical Properties: Viscosity, density, metal particles (size, shape, distribution).
- Chemical Properties: Oxidation level, impurity content (e.g., moisture, oxides).
- Test Methods: Viscometer, microscope, spectral analysis.
JIS-Z-3284 & JIS-Z-3197 Standards
- Viscosity Testing: Malcom viscometer, measured at 25°C.
- Flux Content: Gravimetric method, deviation ≤ ±0.5%.
- Spreadability Test: Measures wettability; acceptable spread rate 70–80%.
- Particle Size: T4 (20–45 μm), T5 (15–25 μm), T6 (5–15 μm) ensure printing stability.
- Thixotropic Index: Ti = 0.4–0.6, R ≈ 0.
IV. Environmental Factors and Operating Norms
- Temperature Control: 25 ± 0.5°C, humidity 30–60% RH to reduce interference.
- Sample Handling:
- Stand for 30 min to remove bubbles.
- Avoid air introduction, stir for 1–2 min.
- Equipment Maintenance:
- Clean spindle and sample cup with ethanol after each test.
- Regularly calibrate instruments (e.g., Malcom PCU-205).
V. Impact of Viscosity on SMT Process
- High Viscosity:
- Causes printing blockages, poor paste transfer.
- Requires higher squeegee pressure, risking stencil deformation.
- Low Viscosity:
- Leads to slumping, solder balling, or bridging.
- Increases risk of component shifting after printing.
VI. Process Optimization Recommendations
- Select Viscosity by Application:
- High-speed printing: Use low-viscosity paste (e.g., 100–150 mPa·s).
- Precision components: Use high-viscosity paste (e.g., 150–220 mPa·s).
- Special environments: Use ultra-high viscosity paste (>300 Pa·s), e.g., automotive/aerospace micro bumps.
- Monitor Thixotropic Performance:
- Ti: 0.4–0.6, R ≈ 0 for printing stability.
- Environmental Control:
- Workshop temp: 23–27°C, RH 30–60%.
- Refrigerate paste (0–5°C), warm to room temp before use.
VII. Application Cases
- Smartphone Mainboard Soldering:
- Low-viscosity paste (100–180 Pa·s) prevents shorts between components.
- Printing speed increased by 30%, production cycle shortened.
- Automotive Electronics Soldering:
- High-viscosity paste (200–300 Pa·s) withstands high temp/humidity.
- Solder joint reliability improved by 50%, defect rate reduced below 0.1%.
Conclusion
Solder paste viscosity standards must be determined by application, test method, and industry norms. By precisely controlling viscosity and thixotropic behavior, SMT process yield can be significantly improved, avoiding printing defects and soldering issues. Manufacturers should establish robust quality management systems and routinely verify solder paste performance to meet evolving process demands.
