Preface
The Radeon RX 6750 XT is a graphics card released by AMD in 2022. Although it’s a three-year-old product, its memory bus width (192-bit) and VRAM capacity (12GB) are higher than those of the GeForce RTX 5060 (128-bit, 8GB), giving it better specifications on paper.
However, the GeForce RTX 5060 has advantages in architecture, manufacturing process, and GDDR7 memory, so its performance may not be much worse than that of the Radeon RX 6750 XT. This article will compare the gaming performance of the GeForce RTX 5060 and the Radeon RX 6750 XT for the reference of interested readers.
02
Specifications Comparison
The GeForce RTX 5060 was released on May 19, 2025, using the GB206 GPU based on the Blackwell architecture, manufactured with TSMC’s 4nm process. It has 3,840 CUDA cores, 120 texture units, 48 raster units, 30 SMs, 120 tensor cores, 30 ray tracing units, and 32MB of L2 cache.
Its base clock is 2,280 MHz, boost clock is up to 2,497 MHz, and it’s equipped with 8GB of GDDR7 memory. The memory speed is 28 Gbps, with a 128-bit bus width, 448.0 GB/s bandwidth, FP32 performance of 19.18 TFLOPS, power consumption of 145W, and a suggested retail price of $299.
The Radeon RX 6750 XT was released on March 3, 2022, using the Navi 22 GPU manufactured with TSMC’s 7nm process. It features 2,560 stream processors, 64 raster units, 160 texture units, 40 compute units, 40 ray tracing units, 3MB of L2 cache, and 96MB of L3 cache.
Its base clock is 2,150 MHz, boost clock is up to 2,600 MHz, and it comes with 12GB of GDDR6 memory. The memory bus width is 192-bit, memory speed is 18 Gbps, memory bandwidth is 432 GB/s, FP32 performance is 13.31 TFLOPS, power consumption is 250W, and the suggested retail price is $549.
03
Test Platform Configuration
The main configuration is as follows:
Processor: Ryzen 7 9800X3D
Motherboard: MSI MPG X670E CARBON
Memory: 32GB DDR5 6000MHz
Graphics cards: GeForce RTX 5060 and GeForce RTX 5060 Ti 16GB
Storage: Two Samsung 970 SSDs
Operating System: Windows 11
04
Game Testing (RTX 5060 or RX 6750 XT)
Seven games were tested below, all using 1080P quality settings. In each series of images, the left represents the GeForce RTX 5060 platform, and the right represents the Radeon RX 6750 XT platform.
First Game: Ghostwire: Tokyo
GeForce RTX 5060 platform: average FPS 75, minimum FPS 73, frame time 12.8ms, CPU usage 11%, CPU power 46W, temperature 49°C, memory usage 11.4GB, GPU usage 100%, VRAM usage 5.7GB, GPU power 144W, temperature 57°C.
Radeon RX 6750 XT platform: average FPS 92, minimum FPS 88, frame time 10.8ms, CPU usage 11%, CPU power 47W, temperature 47°C, memory usage 12.0GB, GPU usage 99%, VRAM usage 7.2GB, GPU power 191W, temperature 60°C.
CPU usage is the same; RX 6750 XT uses 0.6GB more RAM, 1.5GB more VRAM, 47W more power, and is 3°C hotter. RX 6750 XT leads by 17 FPS average, 15 FPS minimum, and 2ms lower frame time.
Second Game: God of War
GeForce RTX 5060 platform: average FPS 101, minimum FPS 96, frame time 9.7ms, CPU usage 22%, CPU power 51W, temperature 62°C, memory usage 12.8GB, GPU usage 100%, VRAM usage 6.1GB, GPU power 141W, temperature 55°C.
Radeon RX 6750 XT platform: average FPS 91, minimum FPS 88, frame time 10.7ms, CPU usage 14%, CPU power 46W, temperature 50°C, memory usage 13.2GB, GPU usage 100%, VRAM usage 6.7GB, GPU power 209W, temperature 63°C.
RX 6750 XT has 8% lower CPU usage, 0.4GB more RAM usage, 0.6GB more VRAM, 68W higher power, 8°C higher temperature. RTX 5060 wins by 10 FPS average, 8 FPS minimum, and 1ms faster frame time.
Third Game: Cyberpunk 2077
GeForce RTX 5060 platform: average FPS 84, minimum FPS 70, frame time 11.9ms, CPU usage 51%, CPU power 79W, temperature 61°C, memory usage 11.6GB, GPU usage 98%, VRAM usage 6.8GB, GPU power 140W, temperature 56°C.
Radeon RX 6750 XT platform: average FPS 82, minimum FPS 68, frame time 12.3ms, CPU usage 48%, CPU power 75W, temperature 57°C, memory usage 11.7GB, GPU usage 99%, VRAM usage 7.8GB, GPU power 209W, temperature 60°C.
RX 6750 XT uses 3% less CPU, 1GB more VRAM, 69W more GPU power, and is 4°C hotter. Performance is nearly identical; RTX 5060 is ahead by 2 FPS.
Fourth Game: Horizon Forbidden West
GeForce RTX 5060 platform: average FPS 90, minimum FPS 79, frame time 10.8ms, CPU usage 45%, CPU power 81W, temperature 64°C, memory usage 11.8GB, GPU usage 99%, VRAM usage 7.5GB, GPU power 143W, temperature 55°C.
Radeon RX 6750 XT platform: average FPS 89, minimum FPS 79, frame time 10.6ms, CPU usage 35%, CPU power 77W, temperature 61°C, memory usage 12.1GB, GPU usage 99%, VRAM usage 8.1GB, GPU power 205W, temperature 61°C.
RX 6750 XT uses 10% less CPU, 0.3GB more RAM, 0.6GB more VRAM, 62W more power, and is 6°C hotter. Both platforms perform equally.
Fifth Game: Forza Horizon 5
GeForce RTX 5060 platform: average FPS 133, minimum FPS 108, frame time 7.5ms, CPU usage 18%, CPU power 58W, temperature 53°C, memory usage 12.3GB, GPU usage 98%, VRAM usage 8.0GB, GPU power 128W, temperature 53°C.
Radeon RX 6750 XT platform: average FPS 128, minimum FPS 102, frame time 8.7ms, CPU usage 20%, CPU power 55W, temperature 50°C, memory usage 14.1GB, GPU usage 100%, VRAM usage 9.6GB, GPU power 189W, temperature 60°C.
RX 6750 XT has 2% higher CPU usage, 1.8GB more RAM, 1.6GB more VRAM (RTX 5060 clearly maxed out), 61W higher GPU power, 7°C hotter. RTX 5060 is ahead by 5 FPS, 6 FPS minimum; nearly a draw.
Sixth Game: S.T.A.L.K.E.R. 2
GeForce RTX 5060 platform: average FPS 61, minimum FPS 50, frame time 16.9ms, CPU usage 23%, CPU power 76W, temperature 70°C, memory usage 16.8GB, GPU usage 98%, VRAM usage 7.0GB, GPU power 131W, temperature 54°C.
Radeon RX 6750 XT platform: average FPS 54, minimum FPS 47, frame time 19.1ms, CPU usage 20%, CPU power 58W, temperature 50°C, memory usage 24.6GB, GPU usage 99%, VRAM usage 7.9GB, GPU power 210W, temperature 61°C.
RX 6750 XT uses 3% less CPU, 7.8GB more RAM, 0.9GB more VRAM, 79W more GPU power, and is 7°C hotter. RTX 5060 leads by 7 FPS average, 3 FPS minimum.
Seventh Game: The Last of Us Part II
GeForce RTX 5060 platform: average FPS 90, minimum FPS 71, frame time 10.8ms, CPU usage 39%, CPU power 97W, temperature 71°C, memory usage 13.0GB, GPU usage 99%, VRAM usage 7.5GB, GPU power 122W, temperature 51°C.
Radeon RX 6750 XT platform: average FPS 80, minimum FPS 68, frame time 12.4ms, CPU usage 33%, CPU power 62W, temperature 58°C, memory usage 14.2GB, GPU usage 99%, VRAM usage 9.8GB, GPU power 200W, temperature 60°C.
RX 6750 XT uses 6% less CPU, 1.2GB more RAM, 2.3GB more VRAM, 78W more GPU power, 9°C hotter. RTX 5060 leads by 10 FPS average, 3 FPS minimum, 2ms better frame time.
05
Comparison Conclusion
Judging purely from the final gaming performance results, the Radeon RX 6750 XT and GeForce RTX 5060 deliver very similar outcomes, with only minor differences either way, essentially making it a tie — the two are evenly matched.
On the other hand, the GeForce RTX 5060 demonstrates higher CPU performance, lower memory consumption, and significantly lower power consumption and temperatures, offering several overall advantages. Given these factors, and following the principle of choosing newer hardware over older models, the GeForce RTX 5060 is clearly the better choice.
