In AI chip packaging, selecting suitable solder paste requires comprehensive consideration of chip power density, packaging process, reliability requirements, and thermal performance. Based on industry trends and material characteristics, the following solder paste types are more advantageous:
I. Alloy Composition Selection
Comparison between SAC305 and SAC405
SAC405: Increased silver content by 1% improves mechanical strength by about 15%, but cost rises by 20%-30%, suitable for scenarios with stringent reliability demands (e.g., data center GPUs).
SAC305: Balanced in cost and performance, applicable to most AI chips, especially devices requiring long-term stable operation.
Alternative: SAC-X series (e.g., SAC-Q with trace Ni, Sb/Bi) optimizes thermal fatigue resistance through alloying, with cost between SAC305 and SAC405.
Low-Temperature Solder Paste (Sn-Bi) Risk Control
Brittleness Improvement: Adding trace In (indium) or Ag (silver) improves ductility, but the amount (<3%) must be controlled to avoid melting point fluctuation.
Underfill Adhesive: Epoxy-based adhesive is recommended, with curing temperature below 120°C to prevent secondary thermal damage.
II. Particle Size (Type) Optimization Recommendations
Type 4-Type 6 Application Scenarios
Type 4: Suitable for 0.4-0.6mm pitch BGA, LGA packages, printing accuracy ±10μm.
Type 5: Suitable for 0.3-0.4mm pitch flip chips, μBumps, printing accuracy ±10μm.
Type 6-8: Suitable for <0.3mm pitch flip chips, μBumps, printing accuracy ±5μm.
Trend: With increasing integration of AI chips, demand for Type 6 and above will continue to grow.
New Particle Technologies
Nano-scale Powder (T9, T10 ultra-fine solder powder): Particle size <5μm, suitable for <20μm pitch HBM stacking, requires specialized equipment (e.g., laser transfer).
Sphericity Control: Particle sphericity >95% reduces printing issues, enhances solder joint consistency.
III. Flux Type Technical Details
No-Clean Flux
Activity Level: M (medium activity) or L (low activity) is recommended to avoid corrosion of sensitive components from high activity flux.
Residue Control: Must pass ion contamination test (e.g., IPC-TM-650 2.3.25), ensuring halide equivalent <1.5μg/cm².
Water-Soluble Flux (OR)
Cleaning Process: Recommended to use deionized water + ultrasonic cleaning at 50-60°C for 3-5 minutes.
Environmental Compliance: Must meet RoHS 2.0 standards and avoid halogenated fluxes.
IV. Thermal Performance Optimization
Thermal Conductivity Enhancement
Nano Metal Particles: Cu nanoparticles (<50nm) can improve thermal conductivity by 10%-15%, but content must be controlled (<1%) to avoid melting point fluctuation.
Composites: SAC305 + Al₂O₃ nanoparticles (<100nm) can achieve 60-80 W/m·K thermal conductivity, suitable for high-power AI chips.
Thermal Fatigue Resistance
Trace Ni Addition: 0.05%-0.3% Ni can inhibit IMC growth and extend solder joint lifespan.
Alloy Design: SAC-X series adjusts Ag/Cu ratio to optimize thermal cycling performance.
V. Key Considerations for Process Compatibility
Reflow Temperature Profile Optimization
Temperature Range: Recommended peak temperature 240-250°C for 60-90 seconds to ensure full solder joint melting.
Ramp Rate: Control at 2-3°C/s to avoid thermal shock.
Advanced Packaging Compatibility
Heterogeneous Integration: Layered soldering (e.g., SAC305 + Sn-Bi combination) is recommended — first solder core chip at high temperature, then sensitive structures at low temperature.
3D IC Stacking: For multiple reflows, select alloys with strong thermal degradation resistance (e.g., SAC-X series), and optimize temperature profiles to reduce thermal damage.
VI. Practical Application Case Studies
High-Performance AI Chips (e.g., NVIDIA/AMD)
Solution: SAC305 (Fitech FR209) + Type 4/5 + No-Clean Flux
Advantages: High silver content resists thermal fatigue, fine particles match micro-pitch, minimal residue compatible with subsequent processes.
Validation: Passed thermal cycling test (1000 cycles, -40°C~125°C), void rate <5%.
Automotive/Server AI Chips
Solution: SAC405 + High Activity Flux
Advantages: Withstands extreme temperatures, strong wettability ensures reliable connections.
Validation: Drop test (1.5m, 3 drops on each of 6 sides), no solder joint cracking.
Consumer Electronics (Edge AI)
Solution: SnCu or Sn-Bi + Type 4
Advantages: Balances cost and performance, low-temperature process reduces thermal damage.
Validation: Shear test (>20N), solder joint strength qualified.
VII. Supplemental Validation Procedures
Process Testing
Printing Test: Validate solder paste release and printing consistency (e.g., CTQ indicators: bridging rate <0.5%, slump rate <10%).
Reflow Simulation: Analyze temperature distribution via thermal imaging to ensure uniformity.
Reliability Testing
Thermal Cycling: Perform 1000 cycles (-40°C~125°C), monitor solder joint resistance changes.
Drop Test: 1.5m height, 3 drops on each of 6 sides, check for solder joint cracks.
Shear Test: Test solder joint strength, ensure >20N.
Microscopic Analysis
SEM/EDS: Examine IMC layer thickness (1-3μm), uniformity, and void rate (<5%).
X-ray Inspection: Analyze internal solder joint defects, ensure no voids or cracks.
VIII. Summary and Recommendations
| Scenario | Recommended Solution | Key Reason |
|---|---|---|
| High-performance AI chips (HPC/servers) | SAC305/FR209 + Type 4/5 + No-Clean | High silver content resists thermal fatigue, fine pitch compatibility |
| Automotive/Industrial AI modules | SAC405 + High-activity flux | Extreme temperature resistance, strong wettability |
| Low-cost edge AI devices | SnCu or Sn-Bi/FL170 + Type 4 | Balanced cost and performance, low-temp process reduces thermal damage |
| 3D packaging/interface integration | Sn-Bi/FL170 + Underfill adhesive | Low-temp reflow protects sensitive structures, requires mechanical support |
IX. Future Trends
Nanomaterial Applications: Graphene, carbon nanotubes enhance thermal conductivity, reduce thermal resistance.
Hybrid Bonding Compatibility: Develop composite materials compatible with both Cu-Cu hybrid bonding and solder paste welding.
AI-Driven Design: Use machine learning to optimize solder paste composition and process parameters.
Through comprehensive consideration of alloy composition, particle size, flux type, thermal performance, and process compatibility, the electrical, thermal, and reliability performance of AI chips can be significantly improved to meet high computing power and low power consumption demands.
