2.5inch SATA3 6GB/s SSD

It supports hardware encryption, power fails protection and overload protection

Share:

Additional information

Weight 80 g
Dimensions 100.4 × 70 × 7 mm
Brand

ODM/OEM

Interface

SATA3 6GB/s

Type

2.5inch

Capacity

60GB, 120GB, 240GB, 480GB, 960GB, 1920GB

Storage Media

MLC, TLC, QLC

Warranty

Limited 5-year warranty with free technical support

Payment Term

T/T, Western Union, MoneyGram, PayPal

You will get our reply within 24 hours.

Description

Overview

DiskMFR’s 2.5” SSD has the SATA III interface and is fully compliant with the standard 2.5-inch Form Factor.

The SATA 3 SSD 2.5” offers advanced features like physical destruction, secure erase, and high reliability. It supports hardware encryption, power fails protection, and overload protection. It also supports military applications.

The SATA 3 SSD has a high endurance that features advanced flash management and is backward compatible with SATA II (3Gb/s) and SATA I (1.5Gb/s). This enterprise-class SSD support AES Encryption/TCG OPAL. The enterprise SATA SSD is also compliant with MIL-STD-810-F/G and RoHS.

The SATA 3 SSD 2.5″ comes in many flash types offering different capacities. These enterprise SSDs are suitable for server raid and other write-intensive applications.

Physical dimensions and weight

Model Heightmm Widthmm Lengthmm Weight g
DSD25B58XXXTC 7.0 Max 10.45+/-0.15 69.85+/-0.15 TBD

External Transfer Rate (Host Transfer Rate): 6Gbps

Density 60GB 120GB 240GB 480GB 960GB 1920GB
Write (MB/S) 250 300 350 400 450 500
Read (MB/s) 450 480 500 510 520 530

Features

  • Form factor: 100.45MM(L) X 69.85MM(W)
  • Input voltage: 5.0V (±5%)
  • Commercial operating temperature range from 0 to +70℃
  • Flash management algorithm: static and dynamic wear-leveling, bad block management algorithm
  • Supports dynamic power management and SMART (Self-Monitoring, Analysis, and Reporting Technology), NCQ, Trim
  • ECC (Error Correction Code): Hardware LDPC ECC engine with hard-decision and soft-decision decode
  • Write endurance: >8 years @ 100GB write/ day(60GB)
  • Read endurance: unlimited
  • Data retention: 10 years
  • MTBF:1,200,000 Hours

CrystalDiskMark Test Results

Part No. Capacity Firmware Version Read/Write Speed(Mbytes/second)
CrystalDiskMark 7.0
Seq(Q8T1) Seq(Q1T1) 4K(Q32T16) 4K(Q1T1)
FLD25B58120TC 120GB T0910 300/480 290/470 170/200 35/90
FLD25B58240TC 240GB T0910 350/500 320/470 200/230 39/95
FLD25B58480TC 480GB T0910 400/510 350/480 240/260 40/100
FLD25B58960TC 960GB T0910 450/520 380/480 270/270 42/102
FLD25B5902TTC 1920GB T0910 550/530 420/480 280/280 44/104

Ordering Information

DSD25B5809xxxTC

DSD: DiskMFR disk

25B:2.5Inch SATA III Interface

58:Controller is SM2258XT/59XT

xxx: Density

TC: Based on TLC NAND Flash

xxx Density
060 60GB
120 120GB
240 240GB
480 480GB
01T 960GB
02T 1920GB

Factory Profile

OEM/ODM Manufacturer

DiskMFR™ is a world-leading supplier specializing in the research and development, design, manufacturing, and marketing of industrial solid-state disks (SSD), consumer digital products such as memory card/USB Flash disk, and memory modules.

Since its establishment in 2009, DiskMFR™ has developed innovative products and services based on its commitment to helping customer“access the best”. Our customers include global distributors, equipment manufacturers, and retailers.

We offer high-performance, high-reliability, and high-value memory modules and flash memory products for the industrial control market; for consumers, we design innovative digital storage and peripheral products for everyday use in the recording, storing, and sharing of digital data.

FAQs

Q1: Do you accept ODM/OEM orders?

Of course. We provide experienced one-stop OEM and ODM service. We own the modern factory and professional R & D. Give us your idea for your own product, then we can make it come true.

Q2: How can you guarantee the production quality?

From raw material to finished products, we employ a higher standard at every step of manufacturing. Strict tests and inspections are conducted to guarantee each piece of our SSD and USB flash drives are in perfect condition before shipping.

Q3: What is your MOQ?

Most of our products are in stock, with no request for MOQ. For some products with customized silk printing, we request MOQ 50pcs per design. For special requirements, welcome to contact us.

Q4: Do you provide samples of product?

Yes! Welcome to samples to test and check the goods’ quality, Mixed samples are acceptable.
